Comfort Level; Battery Replacement - TFA 30.3057.01 Mode D'emploi

TFA_No. 30.3057_Anleit_02_22 09.02.2022
MULTI-SENS – Wireless Thermo-hygrometer
• When the maximum or the minimum values are displayed, press and hold the MaxMin/+ button for four
seconds to reset the corresponding values.
• Press the MaxMin/+ button again to return to normal mode.
• The maximum and minimum values are automatically reset at midnight.

8.4 Comfort level

• Smiley Temperature
☺
+19°C ... +25°C
• When the temperature is between 19 °C and 25 °C and the humidity between 40% and 60% (comfort level
range) a smiling face appears on the display. If the values are outside this range, a sad face appears
instead.
9. Positioning and mounting of the base station and the transmitters
• Place the base station at the final position. Avoid the vicinity of any source of interference such as comput-
er screens, TV sets or solid metal objects.
• The transmitter can be wall mounted (mounting hole at the back). When placed outdoors, choose a shady
and dry place for the transmitter. Direct sunlight may trigger incorrect measurement and continuous
humidity strains the electronic components needlessly.
• Once the desired location is chosen, check if the transmission from transmitters to the base station is pos-
sible (transmission range of up to 80m in open areas), within solid walls, especially with metal parts, the
transmission range can be considerably reduced.
• If necessary choose another position for the transmitter and/or base station.
10. Transmitter sites labelling
• You can name the three sites on the base station display once the transmitters 1-3 have been permanently
installed at the desired location. Please use a correctable pen (e.g.: Staedtler Lumocolor correctable pen).
11. Care and maintenance
• Clean the devices with a soft damp cloth. Do not use solvents or scouring agents.
• Remove the batteries if you do not use the devices for a long period of time.
• Keep the devices in a dry place.

11.1 Battery replacement

• When the battery symbol appears on a channel display, change the batteries of the respective transmitter.
• Change the batteries of the base station, when the battery symbol appears on the display of the indoor values.
• Please note: When the batteries are changed, the contact between transmitter and base station must be
restored – so always start a manual transmitter search or make a restart according to the manual.
12. Troubleshooting
Problems Solution
➜ Ensure the batteries polarity are correct
No indication
➜ Change the batteries
at the base station
➜ Activate DCF reception in the setting mode
No DCF reception
➜ Wait for an attempt reception during the night
➜ Choose another place for the base station
16
15:56 Uhr Seite 9
Humidity
40%...60%
MULTI-SENS – Wireless Thermo-hygrometer
➜ Set the clock manually
➜ Check if there is any source of interference.
➜ Restart the base station according to the manual
➜ No transmitter installed
No transmitter reception
➜ Check batteries of transmitter (do not use rechargeable batteries!)
Display "---"
➜ Restart the transmitter and the base station according to the manual
➜ Search the transmitter manually according to the instruction manual
➜ Choose another place for the transmitter and/or the base station
➜ Reduce the distance between the transmitter and the base station
➜ Check if there is any source of interference.
➜ Change the batteries
Incorrect indication
If your device fails to work despite these measures contact the retailer where you purchased the product
13. Waste disposal
This product and its packaging have been manufactured using high-grade materials and components which
can be recycled and reused. This reduces waste and protects the environment.
Dispose of the packaging in an environmentally friendly manner using the collection systems that have been
set up.
Disposal of the electrical device
Remove non-permanently installed batteries and rechargeable batteries from the device and dis-
pose of them separately.
This product is labelled in accordance with the EU Waste Electrical and Electronic Equipment
Directive (WEEE).
This product must not be disposed of in ordinary household waste. As a consumer, you are
required to take end-of-life devices to a designated collection point for the disposal of electrical
and electronic equipment, in order to ensure environmentally-compatible disposal. The return
service is free of charge. Observe the current regulations in place!
Disposal of the batteries
Never dispose of empty batteries and rechargeable batteries with ordinary household waste. They
contain pollutants which, if improperly disposed of, can harm the environment and human health.
As a consumer, you are required by law to take them to your retail store or to an appropriate col-
lection site depending on national or local regulations in order to protect the environment. The
return service is free of charge.
The symbols for the contained heavy metals are: Cd=cadmium, Hg=mercury, Pb=lead.
14. Specifications
Measuring range
Indoor temperature 0 °C... 50°C (+32 °F ...+122 °F)
Indoor humidity 1% to 99% rH
Temperature (transmitter) -40 °C... 60 °C (-40 °F ...140 °F)
17
