4
1.1

DIMENSIONS

EN
1.2

LISTING APPROVALS

This appliance has been tested in accordance with the CSA Standards for fi xed and location-dedicated electric
room appliances in the United States and Canada. If you need assistance during installation, please contact
your local dealer.
NOTE: This appliance must be electrically wired
and grounded in accordance with local codes
or, in the absence of local codes, with National
Electric Code ANSI/NFPA 70-latest edition in the
United States or the Canadian Electric Code,
CSA C22.1 in Canada.
W415-1223 / A / 01.11.14

FRONT VIEW

49 7/8" [1266mm]
TOP VIEW
43 1/2" [1105mm]
19 7/8"
[505mm]
POWER
SWITCH
Model Number EFL50H
Description Wall-Mount
Appliance
Voltage 120V AC
Watts Max 1500W
Amps 15 AMP Grounded
Circuit
Appliance Width 49 7/8" (1266mm)
Appliance Height 19 7/8" (505mm)
Appliance Depth 4 7/8" (124mm)
Net Weight 56 lbs (25kg)
Gross Weight 77 lbs (35kg)
SIDE VIEW
4 7/8"
[124mm]
17 1/8"
[435mm]
NLF50H
Wall-Mount
Appliance
120V AC
Max 1500W
15 AMP Grounded
Circuit
49 7/8" (1266mm)
19 7/8" (505mm)
4 7/8" (124mm)
56 lbs (25kg)
77 lbs (35kg)
