UNPACKING AND CHECKING CARTON
1 Carry Handle
2 Power Head
3 Power Take-off Socket
4 Suction Port
5 Container
6 Front Caster
7 Anti-static Chain
8 Rear Wheel
9 Latch
10 On/Off Switch
11 Power Cord Storage Hook
12 Exhaust Filter Door
13 Accessory Storage
14 Suction Hose
NOTE: A Phillips screwdriver is required.
1. Remove all the contents from inside of the vacuum cleaner container.
2. Turn the container upside down. Insert two rear wheels and two front casters into the slots and
apply pressure until they click into place. Secure them with supplied screws (Fig. 1 & 2).
3. Your vacuum cleaner comes ready for dry vacuum cleaning with the cartridge filter and nylon
pre-filter pre-installed. If the cartridge filter and nylon pre-filter are not installed, refer to page 10.
4. Optionally, for improved dust filtration, fully fit the dust bag flange onto the inlet stub (Fig. 3).
5. For wet vacuuming, replace the cartridge filter and nylon pre-filter with the foam filter supplied.
Do not use a dust bag when wet vacuuming. If the foam filter is not installed, refer to page 11.
6. Secure the power head back on the container, using the 2 side latches. Insert the locking end
of the hose into the suction port of the container and turn clockwise to lock into place (Fig. 4).
7. Choose the desired accessories and/or extension wands and push fit onto the hose nozzle.
CONTENTS
15 Nylon Pre-filter
16 Crevice Tool
17 Hard Floor Nozzle
18 Round Dust Brush
19 Extension Wand (x2)
20 Cartridge Filter (pre-installed)
21 Filter Retainer (pre-installed)
22 Exhaust Filter (pre-installed)
23 Dust Bag
24 Foam Filter
25 Handle with Air Flow Regulation
26 Screw (x4)
27 Instruction Manual
