Po- Green
wer
Am-
ber
Note
• The Status LED can be configured to be unlit during normal
operation. To configure, go to Setup > System Options > Ports
& Devices > LED. See the online help for more information.
• The Status LED can be configured to flash while an event is
active.
• The Status LED can be configured to flash for identifying the
unit. Go to Setup > System Options > Maintenance .
• The Network LED can be disabled so that it does not flash when
there is network traffic. To configure, go to Setup > System
Options > Ports & Devices > LED. See the online help for more
information.
Connectors and Buttons
For specifications and operating conditions, see page 15.
Network Connector
RJ45 Ethernet connector with Power over Ethernet (PoE).
NO TICE TICE
NO NO TICE
The product shall be connected using a shielded network cable
(STP). All cables connecting the product to the network shall
be intended for their specific use. Make sure that the network
devices are installed in accordance with the manufacturer's
instructions. For information about regulatory requirements, see
Electromagnetic Compatibility (EMC) on page 2.
Normal operation.
Flashes green/amber during firmware upgrade.
13
AXIS F44 Main Unit
