7. PROGRAMMING
Press the PROGRAMMING button. The red programming LED turns on and a long beep
is heard. (If a relay is in bi-stable mode and engaged when this operation is performed,
it becomes disengaged.)
Then enter and validate the four-digit password using the increase digit, reduce
digit, change digit validate password buttons. When a wrong password is validated,
C
you are asked to re-enter the password. If the error is repeated three times or over 30
seconds pass after activating the programming mode before the password is re-entered,
A1A1 is displayed on the screen and the central unit is blocked for 2 minutes. (If the
power supply is reset, the 2-minute delay is reset as well.)
Then send the code(s) to be programmed by pressing the transmitter button and inserting
the smart card in the access control to enable the codes. After each different code is
stored, a short beep is heard and the position is recorded as occupied. The unit decimal
point turns on.
To complete the programming, press FUNCTION. The green operating LED lights up and
two short beeps are heard.
7.1 PROGRAMMING WITH PORTABLE PROGRAMMER
Never insert the memory card when the controller is in programming mode. It
is essential to go into function mode or to disconnect the power supply, otherwise
STOP
the memory may be affected.
• Take the memory card out of the controller.
• Insert it into the connector provided for this purpose on the portable programmer.
• Carr y out the desired operations (writing reser ve codes, copies, etc.)
• Insert the memory card into the controller again.
