Brightness sensor
c. Setting (for operating element 6430 or 6066)
Please proceed as follows to set the threshold value for
the brightness sensor irrespective of the current
brightness:
● Ensure that the brightness sensor is attached at the
planned position and uncovered.
● Change the position of the adjustment knob
– to the right if the sunshade function is to
be actuated at a low brightness value,
– to the left if the sunshade function is
only to be actuated at high brightness
value.
● Saving the current brightness as desired threshold
value for the brightness sensor:
If the current brightness is to be stored as a threshold
value, the adjustment knob (Fig. 5, Pos. 7) must first of
all be turned to the minimum value (all the way to the
right). Wait for a few seconds and then turn it to the
ENG
Fig. 10
