Features
IEC-60320-C13
IEC-60320-C19
21-03-398-933145.indb 7 21-03-398-933145.indb 7
Outlets: During normal operation, the outlets distribute AC power to
connected equipment.
NEMA 5-15/20R
Circuit Breaker (Select Models): Each phase has its own breaker. If
the connected equipment load exceeds the Maximum Load Rating for
that phase of the PDU, the circuit breaker will trip. Disconnect excess
equipment and allow the breaker to cool before resetting the breaker.
Cord Retention Bracket: Provides secure attachment points for
connected equipment cords.
Mounting Buttons: Come pre-installed on the back side of the PDU and
are used for toolless mounting. Note: Four additional mounting buttons
are included for alternate rack styles.
PDUMVROTATEBRKT Mounting Accessory: Use these V-shaped
brackets to mount the PDU with its outlets facing the rear of the rack.
Mounting Brackets: Use these brackets to mount the PDU in racks that
are not compatible with toolless button mounting methods.
Ground Screw: Use this to connect any equipment that requires a
chassis ground.
C14 Plug Sleeve: (Optional) Use the included C14 plastic sleeves to
secure plugs to receptacles. Attach the sleeve to the plug, making sure
that the pull tabs remain outside the plug and that the fit is secure. To
unplug equipment properly, use the pull tabs to remove the plug and
sleeve from the receptacle.
C20 Plug Sleeve: (Optional) Use the included C20 plastic sleeves to
secure plugs to receptacles. Attach the sleeve to the plug, making sure
that the pull tabs remain outside the plug and that the fit is secure. To
unplug equipment properly, use the pull tabs to remove the plug and
sleeve from the receptacle.
20 amp (208V)
NEMA L6-20R
7
30 amp (208V)
NEMA L6-30R
