C. THE HELMET
Note:
When replacing the cheek pads,
the Anti-Roll-Off System must be
properly joined to the chinstrap.
For this purpose, the loops on the
free ends of the A.R.O.S. straps –
as shown in the illustration below –
must enclose the corresponding
ends of the chinstrap and the
A.R.O.S. straps must not be twisted
or knotted.
Note:
For size 54/55 helmets, also ensure
that the A.R.O.S. straps are always
threaded through the additional
loops in the back of the neck area.
84

15. VENTILATION SYSTEMS

VENTILATION DEVICE 1 – FACE SHIELD SETTING
The AVENTURO Mod has a face shield that adjusts to several positions.
Depending on your road speed and the tendency of the face shield to
mist up, open the face shield sufficiently wide to stop it misting up but so
that it still protects your eyes from excessive draft.
Urban position
In its second locking position, the face shield is automatically in urban
position. Air entering through the bottom gap flows over the inside of the
face shield and escapes through the opening at the top.
VENTILATION DEVICE 2 – INLET VENT
IN CHIN AREA
The chin ventilation provides centered air supply.
The incoming air is cleaned with a dust filter as
well. The chin ventilation can be opened and
closed by moving the slider up or down.
VENTILATION DEVICE 3 – FACE SHIELD
VENTILATION
To ventilate the face shield, the AVENTURO Mod is
provided with an inlet in the chin area. Irrespective
of riding posture, around 80-90% of the central
airstream flows directly into this inlet when open.
A deflector ensures that the air current ventilates
the face shield effectively even at low road speeds.
You can open and close the inlet by pushing the
vent upwards or downwards.
