4. Installing GPS aerial

F 36 0004 B
Apply the fabric adhesive tape (1) to the edges
o the GPS aerial bracket (2), as shown in the
illustration.
Secure the GPS aerial (3) with pan-head
bolts, M4x16 (4), shims, diameter 4 mm (5),
and nuts, M4 (6).
The illustration shows the instrument cluster
installation compartment.
F 36 0005 B
Unscrew the Philips screw (1).
Insert the pre-assembled GPS aerial with
bracket (2) between the air duct and the instrument
panel, and secure with the Philips screw (1).
Route the aerial cable along the wiring harness to
the glove box and secure with cable ties.

5. Installing loudspeaker

F 36 0006 B
Attach the cut-out template (1) to the right-hand
footwell trim (2).
Remove the noise insulation mat from the inside of
the footwell trim (2) in the area of the loudspeaker
orifice.
Drill out the specified holes (3) with a 4.5 mm
drill bit.
Cut out the middle hole (4) with a 55 mm diameter
disc cutter.
F 36 0007 B
Align the loudspeaker (1) on the trim (2). Press the
cover (3) through from below with four pan-head
bolts (4), M4x16. Tighten the pan-head bolts (4),
M4x16, with four shims (5), diameter 4.2 mm, and
four nuts (6).
a
Take care to ensure that the cover (3) is not
damaged as the bolts are tightened.

6. Preparing glove compartment

The illustration shows the glove compartment
viewed from above.
F 36 0008 B
Dimension A = 230 mm
Dimension B = 20 mm
Mark the grey-backed area (1) onto the glove
compartment (2) and cut out using the
compressed air saw.
File off any burring from the edges.
18
The illustration shows the glove compartment
viewed from the inside.
F 36 0009 B
Insert the navigation computer bracket (1).
Maintain a distance of 3 mm to the side and mark
the holes (2).
Remove the bracket (1) and drill out the holes with
a 5.5 mm drill bit.
F 36 0012 B
Press the bracket (1) onto the navigation
computer (2) and secure with four Philips
screws (3), M4x8.
F 36 0013 B
Insert the bracket (1), together with the navigation
computer (2), in the glove compartment and secure
with three hexagon bolts (3), M5x14, and three
nuts (4), M5, with washers.
b
If necessary, seal the transition between the
navigation computer and the glove compartment
with fabric adhesive tape.
