QUICKLY EVALUATE AP & BRIDGE MODES
Quickly evaluate the ACKSYS device in AP role
You need a second computer (PC2) with a working Wireless connection.
Set up PC2 Wireless network interface according to the default parameters of
the ACKSYS AP device (802.11gn, SSID "acksys", no security).
Quickly evaluate the ACKSYS device in client role
You need two ACKSYS devices, and a second computer (PC2) with a wired
LAN connection.
Set up the IP addresses according to the picture above and set the device
connected to PC2 to Client (infrastructure) role.
From each PC, start a command prompt and run the ping command to verify
the link.
From PC1: type ping 192.168.1.2, verify the answer returned by PC2
« Answer from 192.168.1.2... »
From PC 2: type ping 192.168.1.1, verify the answer returned by PC1
« Answer from 192.168.1.1... »
All 22 LED indicators are OFF
•
Verify the power supply (voltage, cabling).
The relevant LAN1 or LAN2 led indicator stays OFF
•
Check that the remote device is turned ON.
•
Check the Ethernet plugs on both sides.
•
Try to connect to another device.
•
Use the provided ACKSYS M12/RJ45 cable to connect the device.
The Wi-Fi link does not come up
•
Make sure that the Wireless parameters of the Client (case sensitive
SSID, 802.11 mode, radio channel and security) match those of the AP.
•
Check the radio conditions: distance between devices, placement of
antennas, interferences and obstacles to radio waves propagation.
•
Try with all securities and encryption settings temporary disabled.
•
Try another radio channel.
"ACKSYS NDM" doesn't find your device
•
ACKSYS NDM only scans the local network. To reach a device through
a gateway, use the "fileremote products database" function.
•
Check that your firewall does not block the Java machine.
How to restore factory settings
•
If the built-in web-based interface is reachable, you can use your
browser to restore factory settings.
•
Else, power up the unit, wait for the red "Diag" LED to turn green, then
hold down the reset button for at least 2 seconds. Then release it and
wait for the Diag LED to turn on again, meaning that the product
rebooted with its factory settings.
TROUBLESHOOTING
-4-
