Acksys WL-ABOARD Serie Guide D'installation Rapide page 10

Software
Device configuration
Firmware upgrade
SNMP
Operating mode
AP mode only
Network topology
Security
Client/Bridge mode only
Network topology
Security
Mesh mode only
Network topology
Security
Power supply Input
Model WLn-ABOARD
Model WLn-ABOARD/N
Model WLn-ABOARD/24
Model WLn-ABOARD/48
Model WLn-ABOARD/72
Model WLn-ABOARD/110
POE (only for WLn-ABOARD and
WLn-ABOARD/48)
high power option:
/H4 and WLn-RF400MW
Automatic device discovery
Built in web based utility for easy
configuration from any web browser
(username/password protection & https)
Yes (via web browser or "Acksys NDM")
SNMP V1, V2C
AP (Access Point), Repeater,
Bridge/Client, Mesh, WDS
Infrastructure or mesh modes
WEP, WPA-PSK/WPA2-PSK, WPA/
WPA2 with 802.1x authenticator, SSID
visibility status.
infrastructure mode
WEP, WPA-PSK, WPA2-PSK. 802.1x
supplicant. AES/TKIP/WEP by hardware
encryption
802.11s
SAE/AMPE
Wide range dual input power supplies,
from 9V to 56VDC, with polarity
protection. A 15W min. power supply is
required. M12 6-pole connector.
Dual input insulated power supply, 24V
nominal (9V to 36VDC), with polarity
protection. A 15W min. power supply is
required. M12 6-pole connector
Dual input Insulated power supply, 48V
nominal (36V to 68VDC), with polarity
protection. A 15W min. power supply is
required. M12 6-pole connector.
Dual input Insulated power supply, 72V
nominal (43V to 110VDC), with polarity
protection. A 15W min. power supply is
required. M12 6-pole connector.
Dual input Insulated power supply,
110V nominal (66V to 154VDC), with
polarity protection. A 15W min. power
supply is required. M12 6-pole
connector.
These products can be powered by a
PoE+ power source connected to
LAN2. (802.3at)
This option requires a 25W min. power
supply.
-10-
,
ad-hoc mode
