FAST FIND 200, 210
STANDARDS COSPAS-SARSAT
APPLIED T.001/T.007 class2
RTCM SC110 STD 11010.2
ETSI EN 302-152-1
AS/NZS 4280.2
NSS-PLB06
ENVIRONMENTAL
Exterior Finish Highly visible yellow
Sealing Waterproof to 10m (30ft)
(IP 58, IPX8)
Operating Class 2, -20°C to +55°C
temperature (-4°F to +131°F)
Storage Temperature Class 2, -30°C to +70°C
(-22°F to +158°F)
Altitude 40,000 feet
BATTERY
Battery Type 6V Lithium Metal
Battery storage 5 years
Battery By service centre
replacement
Battery use Logged by microcontroller
OPERATION
Activation Three stage manual activation
Self test Tests transmitters,
battery and light
SOS flash light Morse code SOS pattern
(30 operations allowed)
TRANSPORTATION
Air cargo UN 3091, not restricted,
IATA SP 188 - PI 970
GET FOUND WITH
ELECTRICAL
406.037 MHz ± 1KHz, 5W ± 2dB
transmitter
121.5 MHz ± 3KHz, 50mW ± 3dB PERP
transmitter
Homer sweep UP or DOWN
direction
Transmit Antenna Deployable flexible
vertical blade
Programming Optical Infra-red link
interface
PHYSICAL
Fast Find 200, 210 Category 2, will not float
Size (D x W x L) 34 x 47 x 106 mm
(1.34" x 1.85" x 4.17")
Weight 150g ( 5.3 oz)
GPS ( Fast Find 210 only )
50 channel
Receive Antenna Ceramic Patch
GPS Self test Position acquisition test
(10 operations allowed)
PART NUMBER
91-001-200A Fast Find 200 PLB retail pack
Fast Find 210 PLB (with GPS)
91-001-210A
retail pack
FAST FIND 200, 210 models do not float and are not
recommended for use on or in water unless provided
with an auxiliary flotation device.
A Fast Find PLB is not an ELT or an EPIRB and does not
meet the regulatory requirements for an ELT or an EPIRB.
