Radio controlled alarm clock
Thank you for choosing this instrument from TFA.
1. Before you use it
• Please be sure to read the instruction manual carefully. This information will help you
to familiarise yourself with your new device, learn all of its functions and parts, find
out important details about its first use and how to operate it, and get advice in the
event of faults.
• Following the instruction manual for use will prevent damage to the device and loss
of your statutory rights arising from defects due to incorrect use.
• We shall not be liable for any damage occurring as a result of not following these
instructions. Please take particular note of the safety advice!
• Please look after this manual for future reference.
2. Scope of supply
• Radio controlled alarm clock
• Instruction manual
3. Field of operation and all of the benefits of your new instrument at a glance
• Radio controlled clock with highest precision
• Analogue display with pointer
• Display of seconds and date
• Alarm with snooze function

• Backlight

Kat. Nr. 98.1040.01
4. For your safety
• The product is exclusively intended for the field of application described above. The
product should only be used as described within this instruction.
• Unauthorised repairs, modifications or changes to the product are prohibited.
• The product is not be used for medical purpose or for public information, but is
intended only for home use.
Caution!
Risk of injury:
• Keep this instrument and the battery out of reach of children.
1 • Batteries must not be thrown into the fire, short-circuited, taken apart or re-
charged. Risk of explosion!
• Batteries contain harmful acids. Low batteries should be changed as soon as possi-
ble to prevent damage caused by a leaking battery. Never use a combination of old
and new batteries together, or batteries of different types. Wear chemical-resistant
protective gloves and glasses when handling leaked batteries.
Important information on product safety!
• Do not place the unit near extreme temperatures, vibration or shock.
• Protect from moisture.
5. Elements
LCD display (Fig. 1)
A: Time signal symbol
Symbol Daylight Saving Time
Display of seconds and date
Buttons (Fig. 2)
Kat. Nr. 98.1040.01
B: Dial for the alarm time
C: Switch ON/OFF
D: REC button
E: M.SET button
F: RESET button
Housing (Fig. 3)
G: SNOOZE/LIGHT button
H: Battery compartment
6. Getting started
• Open the battery compartment and insert a new battery (1,5 V AA), ensure battery
polarity is correct.
• A brief beep tone will sound and all segments will be shown for few seconds.
• The unit is ready for use.
• The pointers move to 12 o'clock and the clock is trying to receive the radio signal
for 3 - 12 minutes.
• 00 appears on the display and the radio signal symbol flashes.
• When the time code is received, the radio-controlled time will be shown and the
seconds appear on the display.
• The radio signal symbol appears.
• Twelve times a day receives the clock the radio signal.
• Manual initialization can be helpful. Press and hold REC button for 3 seconds. The
pointers move to 12 o'clock and the clock is trying to receive radio signal again.
• If the clock cannot detect the DCF-signal (for example due to disturbances, transmit-
ting distance, etc.), the time can be set manually. The DCF symbol disappears and
the clock will then work as a normal quartz clock. (see: Manual setting of the time).
6.1 Radio-controlled time reception
Kat. Nr. 98.1040.01
The time base for the radio-controlled time is a caesium atomic clock operated by the
Physikalisch Technische Bundesanstalt Braunschweig. It has a time deviation of less
than one second in one million years. The time is coded and transmitted from Main-
flingen near Frankfurt via frequency signal DCF-77 (77.5 kHz) and has a transmitting
range of approximately 1,500 km. Changeover from summer time or winter time is
automatic. In Daylight Saving Time "S" is shown on the LCD. The quality of the recep-
tion depends mainly on the geographic location. Normally there should be no recep-
tion problems within a 1,500 km radius around Frankfurt.
Please take note of the following:
• Recommended distance to any interfering sources like computer monitors or TV sets
is at least 1.5 - 2 metres.
• Inside ferro-concrete rooms (basements, superstructures), the received signal is nat-
urally weakened. In extreme cases, please place the unit close to a window to
improve the reception.
• During nighttime, the atmospheric interference is usually less severe and reception
is possible in most cases. A single daily reception is adequate to keep the accuracy
deviation below 1 second.
7. Operation
• The instrument will automatically quit the setting mode if no button is pressed
within 8 seconds.
7.1 Manual setting of the time
• Press and hold M.SET button for three seconds.
• The radio signal symbol disappears and the indication of seconds stops.
• Hold the button until the desired time is indicated.
• Press the button briefly the pointer moves minute by minute.
• The manually set time will be overwritten by the DCF time when the signal is
Kat. Nr. 98.1040.01
received successfully.
Radio controlled alarm clock
7.2 Setting of the alarm time
• Turn the dial for the alarm time and set your respective alarm time (in direction of
the arrow).
• To activate the alarm function, move the switch ON/OFF upwards (ON).
• When the alarm time is reached, the alarm will ring for 2 minutes.
• If it is not stopped, the alarm will automatically turn off after 2 minutes and will be
reactivated at the same time.
• When the alarm rings, press SNOOZE/LIGHT button and the snooze function is acti-
vated. The backlight turns on for a short time.
• The alarm will be interrupted for 5 minutes.
• The snooze function can be activated up to seven times.
• Move the ON/OFF switch downwards (OFF), the alarm function is deactivated.
7.3 Display of seconds and date
• Once the reception of the DCF time is successful press M.SET button to toggle
between the display of seconds and date:
• Display of date: Press the REC button to toggle between M/D month/day
sequence (American version) or D/M day/month (European version).
Attention: If there is no DCF reception possible only the seconds appear on the display.
7.4 Backlight
• Press SNOOZE/LIGHT button. The backlight will come on for 5 seconds.
8. Care and maintenance
• Clean it with a soft damp cloth. Do not use solvents or scouring agents.
• Remove the battery if you do not use the product for a lengthy period.
• Keep the instrument in a dry place.

8.1 Battery replacement

• Replace the battery when the functions of the instrument become weak.
• Open the battery compartment and insert a new battery 1,5 V AA.
• Making sure the polarity is correct.
• Close the battery compartment again.
9. Troubleshooting
Problems Solutions
➜ Ensure battery polarity is correct
No display / no pointer
➜ Change battery
movement
➜ Press and hold REC button and start a new reception
No DCF reception
➜ Choose another place for the device
➜ Check if there is any source of interference
➜ Wait for attempted reception during the night
➜ Manual time setting
➜ Restart the device as per the manual or use a pin to press
the RESET button
➜ Change battery
Incorrect display
If your device fails to work despite these measures contact the supplier from whom you
purchased it.
10. Waste disposal
This product has been manufactured using high-grade materials and components
which can be recycled and reused.
Never dispose empty batteries and rechargeable batteries in household
waste.
As a consumer, you are legally required to take them to your retail store or
to appropriate collection sites depending to national or local regulations in
order to protect the environment.
The symbols for the heavy metals contained are:
Cd=cadmium, Hg=mercury, Pb=lead
This instrument is labelled in accordance with the EU Waste Electrical and
Electronic Equipment Directive (WEEE).
Please do not dispose of this instrument in household waste. The user is
obligated to take end-of-life devices to a designated collection point for
the disposal of electrical and electronic equipment, in order to ensure
environmentally-compatible disposal.
11. Specifications
Power consumption: Battery 1 x 1,5 V AA (not included)
Housing dimension: 96 x 55 x 119 mm
Weight: 140g (only instrument)
