ASSEMBLY J 100 Ultra
Feed tube
Ejector
Handles
Sieve
9
7
6
10
Alignment markers
1
Motor unit
5
Basket
2
6
Bowl
Pulp container
3
Spout
7
Ejection chute
4
Flange
8
Lid
1
8
Grating disc
5
2
4
2
3
Safety arm
3
1
11
9
Strap
10
Booster base
11
Drip tray
1) Position the motor
4
unit so that the On/Off
buttons are facing you.
5
2) Place the bowl on
top of the motor unit.
3) Fit the flange onto
the rim of the bowl.
The ribs of the flange
should be lined up with
the flat panel of the
bowl. Check that the
flange is correctly
fitted.
You can also refer to the label (below) stuck to the
lid.
4) Lower the basket
into place, holding it
by its handles.
Rotate it until it slots
into place.
5) Line the lid up with
the notches in the
flange
I M P O RTA N T
Make sure that the pin
on the motor shaft is
correctly lined up with
the
corresponding
notch in the basket
hub.
9
