Figures - Laevo STRUCTURES V2.5 Mode D'emploi

3. Move the Torso Structure in the hole to a comfortable
width setting. There are 3 width settings (Figure 4.2).
4.
Release the button (Figure 4.3).
5. Push the button on the left SmartJoint (Figure 4.4).
6. Move the left Torso Structure in the hole to a com-
fortable height setting (Figure 4.5).
7. Rotate the indentations towards the button to make
sure the parts can lock (Figure 4.6).
8.
Release the button (Figure 4.7).
9. Repeat for right side.
5

Figures

Figure 2.1
1.
2.
1
3.
2
3
Laevo | V2.5 LEGPAD EN | P7
Manual
Right Torso Structure
Left Torso Structure
