TECHNICAL DATA

Voltage range ........................................................... 12
Quick charge current ............................................... 3.0
Maintaining charge ................................................. 500 mA
Battery charging time Li-Ion 1.5 Ah ......................... 30 min
Weight according EPTA-Procedure 01/2014 .......... 460
Recommended ambient charging temperature +5...+40 °C
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and instructions
may result in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS – This manual contains
important safety and operating instructions for this battery
charger.
Before using battery charger, read all instructions and
cautionary markings on battery charger, battery and product
using battery.
Failure to follow the warnings and instructions may result in
electric shock, fi re and/or serious injury.
Do not try to charge non-
rechargeable batteries with this
charger.
CAUTION – To reduce risk of
injury, charge only the following
types of re-chargeable batteries:
Battery Cell Type
Cat. No.
Li12B Li-Ion
M12B Li-Ion
Li12BX Li-Ion
M12BX Li-Ion
M12B4 Li-Ion
M12B6 Li-Ion
Other types of batteries may burst, causing personal injury
and damage.
Do not dispose of used battery packs in the household
refuse or by burning them. Your power tool distributor will
normally retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
No metal parts must be allowed to enter the battery section
of the charger (short circuit risk).
Never break open battery packs and chargers and store
only in dry rooms. Keep dry at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new
one.
Before use check machine, cable, and plug for any
damages or material fatigue. Repairs should only be carried
out by authorised Service Agents.
This appliance is not intended to
be used or cleaned by persons
with reduced physical, sensory or
mental capabilities, or lack of
6 ENGLISH
CHARGER
DC Volts Capacity
12 V ≤ 1,5 Ah
12 V ≤ 1,5 Ah
12 V ≤ 3,0 Ah
12 V ≤ 3,0 Ah
12 V ≤ 4,0 Ah
12 V ≤ 6,0 Ah
experience or knowledge, unless
V
they have been given instructions
A
concerning the safe use of the
g
appliance by a person legally
responsible for their safety. They
should be supervised whilst using
the appliance. Children shall not
use, clean or play with this
appliance, which when not in use
should be secured out of their
reach.
Warning! To reduce the risk of fi re, personal injury, and
product damage due to a short circuit, never immerse your
tool, battery pack or charger in fl uid or al-low a fl uid to fl ow
inside them. Corrosive or conductive fl uids, such as
seawater, certain industrial chemicals, and bleach or bleach
containing products, etc., Can cause a short circuit.
SPECIFIED CONDITIONS OF USE
The quick charger is intended to charge batteries from
system Li12.../M12... / 12V.
Do not use this product in any other way as stated for
normal use.
CHARGING TIME
Battery Cat.
No.
Cell No.
Li12B
3
M12B
3
Li12BX
2 x 3
M12BX
2 x 3
M12B4
2 x 3
M12B6
2 x 3
MAINS CONNECTION
Connect only to single-phase a.c. current and only to the
system voltage indicated on the rating plate. It is also
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.
CHARACTERISTICS
After inserting the battery into the reception of the charger
the battery will automatically be charged (red lamp is
illuminated continuously)
When a hot or cold battery pack is inserted into the charger
(fl ashing red lamp), charging will begin automatically once
the battery reaches the correct charging temperature
(0°C...60°C).
Charging time varies depending on the battery temperature,
charge needed and the type of battery pack being charged.
As soon as charging is completed, the charger switches
over to "trickle" charge to maintain the full capacity (green
control lamp is illuminated continuously, red lamp off )
It is not necessary to remove the battery after charging. The
battery can be stored permanently in the charger without the
danger of being overcharged.
If both LEDs fl ash at the same time, either the battery has
not been completely mounted or there is a fault in the
battery or the charger. For safety reasons you must stop
using the charger and battery immediately and have them
inspected by an designated Customer Service Centre.
969.416.00.0(00)
Volts Capacity
12 V ≤ 1,5 Ah
12 V ≤ 1,5 Ah
12 V ≤ 3,0 Ah
12 V ≤ 3,0 Ah
12 V ≤ 4,0 Ah
12 V ≤ 6,0 Ah
Charging Time
30 min
30 min
70 min
70 min
80 min
130 min
