Mounting
Before mounting this product, read the
mounting clamps are capable of supporting the weight of the product. For our Chauvet line of mounting clamps, go to
http://trusst.com/productcategory/truss-clamps/.
Mounting Diagram

Overhead Mounting

Control Panel Description
Button Name
<UP>
< >
<MENU>
< >
<DOWN>
< >
<LEFT>
< >
<ENTER>
< >
<RIGHT>
< >
Battery Powered Display
Press and hold until menu screen appears (approximately 15 seconds).
3
QUICK REFERENCE GUIDE
Safety Notes. Use at least two mounting points per product. Make sure the
Mounting Clamp
Function
Navigates upwards through the menu list or increases the numeric value when in a
function
Exits from the current menu or function
Navigates downwards through the menu list or decreases the numeric value when in a
function
Navigates leftwards through the menu list
Enables the currently displayed menu or sets the currently selected value into the selected
function
Navigates rightwards through the menu list
Safety Cable

Floor Mounting

Maverick MK3 Profile CX QRG Rev. 2
