SCANGRIP Canvik Basic Instructions D'utilisation page 32

Find the latest APPLICATION CAR LIST on our
CANVIK McPherson Coil Spring Compressors 1500 kg and 2250 kg
Article No. 12.0001 1500 kg Coil Spring Compressor complete with 4 standard jaws for
springs ø 80-195 mm (nos. III and V)
Article No. 11.0001 2250 kg Coil Spring Compressor complete with 4 standard jaws for
springs ø 80-195 mm (nos. III and V)
Jaw No. Article No. Description
II 90.0050 Small jaw
III 90.0010 Standard small jaw
IV 90.0030 Middle jaw
Standard large jaw
V 90.0020
VII 90.0040 Large jaw
VIII / IX 90.0100 Jaw for Peugeot Break, Citroën C15 (pair)
X 90.0060 Jaw for conical and ball springs
XI 90.0070 Jaw for BMW E39-46, Renault Megane II, Toyota Avensis
XII 90.0080 Jaw for Mercedes C class, type 203
XIII 90.0090 Jaw for Mercedes E class, type 211, Renault Megane II
90.0120 Jaw for Chrysler Grand Voyager
Indicates conical/ball springs in the list
Please always check the diameter of the spring to be sure to use the right jaw
CANVIK BASIC
website: www.scangrip.com
Application car list for the original
Spring diam.
80-120 mm
80-145 mm
140-175 mm
145-195 mm
180-230 mm
80 -145 mm
Updated August 2008
