Contrôle des réglages - suite
P40 Auto ack alarms
Service
u01 Pc °C
u03 Saux 1 °C
u10 Lowliquid level alarm
u21 Suction superheat K
u37 Common fan safety
u44 Sc3 Air on °C
u48 Condenser status
u49 Cond. Cap %
u50 Request Cond. Cap %
u51 Suction status
u52 Compressor Cap %
u53 Request Comp. Cap %
u54 Sd discharge gas °C
u55 Ss suction gas °C
u87 Load shed input 1
u88 HP common safety
u89 LP common safety
U12 Actual setup
U13 Injection ON
70
W Select whether the controller should auto acknowledge alarms. In stand
alone applications it should be set to Enabled
R Condensing pressure in °C. (measured with the Pc pressure transmitter)
R Air temp Saux temperature in °C
R Actual status of low liquid alarm
R Superheat in suction line
R Actual status of common fan safety input
R Outdoor temperature in °C measured with Sc3 temperature sensor
R Actual control status of condenser
0=Power up
1=Stopped
2=Manual
3=Alarm
4=Restart
5=Standby
10=Full loaded
11=Running
R Cut-in condenser capacity in % (of total capacity)
R Reference for condenser capacity
R Actual control status of suction group
0=Power up
1=Stopped
2=Manual
3=Alarm
4=Restart
5=Standby
10=Full loaded
11=Running
R Cut-in compressor capacity in % (of total capacity)
R Reference for compressor capacity (deviations may be due to time delays)
R Discharge gas temperature in °C
R Suction gas temperature in °C
R Actual status on Load shed input
R Actual status of common HP safety input for all compressors
R Actual status of common LP safety input for all compressors
R Actual selected quic setup
R Status of the "Injection ON" function
Régulation de capacité RS8FT404 © Danfoss 03-2013
0: Enabled 1: Disabled
1: Disabled
ON/OFF
ON/OFF
0-100%
0-100%
0-100%
0-100%
ON/OFF
ON/OFF
ON/OFF
See documenation
for quick selections
ON/OFF
