Operation
Starting the robotic cleaner
Connect the power supply to the wall socket. The on/off button will lit and the robotic
cleaner will start its cleaning program. If the power supply is already connected to the
wall socket, the on/off button will flash to indicate that the robotic cleaner is in standby
mode. Press the On/Off button in order to change the above mode (On to Off – standby,
or vice versa). Note: if the full filter indication light is ON make sure to remove and clean
the filter prior to putting the cleaner inside the pool water.

Cleaning cycle

During the cleaning cycle, the cleaner: (1) moves across the pool floor picking up dirt
and debris. (2) Changes direction and rotates automatically according to the selected
program. (3) Climbs the pool walls every few minutes, as set in its internal program. Note:
The robotic cleaner might occasionally stop moving for a few seconds. This is part of
normal operation, not a malfunction.
Stopping robotic cleaner operation
The robotic cleaner moves automatically to 'standby' after every cleaning cycle and the
on/off button starts flashing. To stop the cleaner operation during a cleaning cycle, press
the operation button once. On/off button starts flashing and the cleaner is in standby
mode.
Pulling cleaner unit out of the water
(1) Unplug the floating cable from the power supply. (2) Pull the floating cable until the unit
is close enough to reach the handle. (3) Using the handle, lift the cleaner out of the pool.
CAUTION: Do not use the floating cable to lift the cleaner out of the water.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference that may be received or that may cause
undesired operation. A distance of at least 20 cm. between the equipment and all persons should be maintained during the operation
of the equipment.
4
L100 / L200 ROBOTIC POOL CLEANERS

Power Supply

On/Off
On/Off
Full filter
indicator
Bluetooth
On/Off
Full filter
indicator
Short
cycle
Bluetooth
Delay
operation
