PART NAMES & CONTROL PANEL
SENSOR COOK
1� Frozen Entrees
2� Ground Meat
3� Rice
4� Chicken Breast
5� Fish/Seafood
8
REHEAT
1� Sensor Reheat
2� Fresh Rolls/Muffins
3� Frozen Rolls/Muffins
4� Pasta
5� Pizza Reheat
5 9
4
3 2
7
1� One touch door open button
Push to open door
2� Microwave oven door with see-through window
3� Safety door latches
The microwave oven will not operate unless the door is securely closed.
4� Door hinges
5� Door seals and sealing surfaces
6� Turntable motor shaft
7� Removable turntable support
Carefully place the turntable support in the center of the microwave
oven floor.
8� Removable turntable
Place the turntable on the turntable support securely. The turntable will
rotate clockwise or counterclockwise. Only remove for cleaning.
9� Ventilation openings (rear)
10� Microwave oven light
It will light when microwave oven is operating or door is open.
11� Waveguide cover: DO NOT REMOVE
12� Auto-Touch control panel
13� Interactive display: 99 minutes, 99 seconds
14� Serial plate
15� Menu label
DEFROST VEGGIES
1� Ground Meat 1� Baked Potato
2� Steak/Chops/Fish 2� Fresh Veggies - Soft
3� Chicken Pieces 3� Fresh Veggies - Hard
4� Roast 4� Frozen Veggies
5� Casserole
6� Soup
15 10
6
14 11 3
8
MELT/SOFTEN
1� Butter
2� Chocolate
3� Ice Cream
4� Cream Cheese
13
12
1
