CONTENU DU KIT

KIT CONTENT
9
7
10T
4-5
24
N° pièce Désignation
0 notice de montage
1 fuselage
1-1 entretoise moteur
1-3 réservoir essence
2 aile avec ailerons et volets
2-2 fixation aile
2-5 tringlerie ailerons+volets
2-8 guignol ailerons+volets
24 clé d'aile
3 empennage horizontal
3C carénage stab.
3-2 fixation empennage hor.
3-5 tringlerie profondeur
3-8 guignol de profondeur
4 dérive
4-2 fixation dérives
4-2R barre dérive
4-4 fixation servos direction
4-5 tringlerie direction
4-8 guignol de direction
6 verrière
7 décoration
8-1 roue train principal
8-3 fixation roue
9 capot moteur
9-0 fixation capot
9-21 tringlerie direction
10M train d'atterrissage principal
10N train avant avec roue
10T tringlerie dirigibilité
10-2M fixation train principal
10-2N fixation train avant
CR crochet de remorquage
2
2
9-0
4-8
2-8/3-8
2-5 2-5
3-5
9-21
Matériau, dimensions (mm) Qté
A4 01
structure bois entoilée 01
aluminium 12
1000cc 01
structure entoilée 02
vis M4x30+rondelle 02+02
quick link+chape 04+08
métal+vis 04+16
tube alu Ø23x770 mm 01
structure coffrée, entoilée 01
plastique+balsa 01
vis M4x30+rondelle 01+01
quick link+chape 01+02
métal+vis 01+04
structure entoilée 02
vis M3x20+rondelle 04+04
tube alu+vis à bois 3,5x9,5 02+04
carénage ABS+bloc bois dur+vis 02+04+12
quick link+chape 02+02
nylon+vis 02 sets
PVC+armature bois 01 set
planche auto-collants 01 set
Ø105mm 02
axe de roue+bague d'arrêt 02+04
fibre de verre peinte 01
vis M3x15 04
quick link+chape 01
aluminium 01
Ø105mm 01
tube alu avec silent-bloc+embout M4 01+01
vis M4x25+rondelle 04+04
vis M3x30+rondelle 04+04
01 set
6
1
2-2/3-2
10M
4-4
10-2M
1-3
8-3 8-1
Part # Item
0 building instructions
1 fuselage
1-1 engine stand-off
1-3 tank for gas
2 wing with ailerons and flaps
2-2 wing fixing
2-5 aileron+flap linkage
2-8 aileron+flap control horn
24 wing joiner
3 horizontal tail
3C stab. cover
3-2 horizontal tail fixing
3-5 elevator linkage
3-8 elevator control horn
4 vertical tail
4-2 vertical tail fixing
4-2R vertical tail reinforcement
4-4 rudder servo fixing
4-5 rudder linkage
4-8 rudder control horn
6 canopy
7 art work
8-1 main wheel
8-3 main wheel fixing
9 engine cowl
9-0 cowl fixing
9-21 throttle linkage
10M main landing gear
10N front landing gear with wheel
10T steering pushrod
10-2M main LG fixing
10-2N front gear fixing
CR remote tow hook
3
4
4
CR
4-2 4-2R
10-2N
3
10N
1-1
8-1 8-3
Material, dimensions (mm)
A4
all built-up, film covered
aluminium
1000cc
all built-up, film covered
screw M4x30+washer
pushrod+clevis
metal+screw
alu tube Ø23x770mm
all built-up, film covered
plastic+balsa
screw M4x30+washer
pushrod+clevis
metal+screw
all built-up, covered
screw M3x20+washer
alu tube +wood screw 3,5x9,5
plastic cover+HW block+screw
pushrod+clevis
nylon +screw
PVC+wood frame
stickers sheet
Ø105mm
axle shaft+collar
painted fiberglass
screw M3x15+washer
pushrod+clevis
aluminium
Ø105mm
alu tube with silent block+M4 coupler
screw M4x25+washer
screw M3x30+washer
Qty
01
01
12
01
02
02+02
04+08
04+16
01
01
01
01+01
01+02
01+04
02
04+04
02+04
02+04+12
02+02
02 sets
01 set
01 set
02
02+04
01
04
01
01
01
01+01
04+04
04+04
01set
