Safety Instructions For Batteries; Remote Control - Revell Control ROXTER Manuel De L'utilisateur

new batteries should be
inserted and/or the batteries
should be charged.
Safety instructions for
batteries:
• Rechargeable batteries must
be removed from the remote
control prior to recharging.
• Non-rechargeable batteries
may not be charged.
• Rechargeable batteries may
only be charged under the
supervision of an adult.
• The combination of different
types of batteries as well as
new and used batteries must
be avoided.
• Only recommended batteries
or those of an equivalent type
may be used.
• Batteries must be inserted
according to the correct
polarity (+ and -).
• Depleted batteries must be
removed from the remote
control.
• The connection terminals may
not be short-circuited.
• Remove the batteries from
the remote control if they are
not to be used for an
extended period of time.
Charging unit safety
instructions:
• Non-rechargeable batteries
may not be charged.
• This charging unit is not
suitable for people (including
children) with physical or
mental limitations, or those
16
with insufficient knowledge
and experience of charging
units, unless under supervision
or following proper directions
from a parent or legal
guardian.
• Children must be supervised –
the charging unit is not a toy!
• The charging unit for the LiPo
battery is specially designed
for the charging of the model
battery. The charging unit may
only be used to charge the
model battery, not other
batteries.
• Transformers, mains adapters
or chargers that are used
together with the model must
be checked regularly for
damage to cables, plugs,
housings and other parts and
any damages must be repaired
before the devices may be
used again.
The model is equipped with a
rechargeable lithium polymer
battery. Please observe the
following safety instructions:
• Never throw LiPo batteries
into a fire or store them in a
hot location.
• Only use the supplied charger
to charge the battery. The use
of a different charger may lead
to the permanent damage of
the battery and neighbouring
parts, as well as physical injury!
• Never use a charger for NiCd/
NiMH batteries!
• Always ensure that the
charging process takes place
on a fireproof surface in a
fire-resistant environment.
• Do not leave the battery
unsupervised during the
charging process.
• Never disassemble or alter the
battery contacts. Do not damage
or puncture the battery cells.
There is a risk of explosion!
• The LiPo battery must be
kept out of reach of children.
• When disposing of batteries,
they must be discharged or
their capacity must be fully
depleted. Cover exposed
terminals with adhesive tape
in order to prevent short-
circuiting!
Maintenance and care:
• Please only use a clean, damp
cloth to wipe off the model.
• Protect the model and
batteries from direct sunlight
and/or direct heat.
• Never allow the remote control
and charging unit to come into
contact with water, because the
electronics will be damaged as
a result.
1 HELICOPTER
1A Counter-rotating rotor blades
1B Stabiliser
1C Infrared receiver

2 REMOTE CONTROL

2A Up/Down thrust control
2B ON/OFF button
2C Infrared transmitter
2D Controller for left/right
Technical changes and
differences in color reserved!
Required batteries for
the multicopter:
Power supply:
Rated output: DC 3.7 V / 0.33 Wh
Batteries: 1 x 3.7 V rechargeable
LiPo battery (interchangeable)
Capacity: 90 mAh
Battery requirement for
the remote control:
Power supply:
DC 6 V
Batteries:
4 x 1.5 V "AA"
(not included)
1D ON/OFF switch
1E Charge socket
2E Left/right trim buttons
2F Charging station
2G Power LED
2H Battery compartment cover
