SCHEU IMPRIMO Cure Mode D'emploi page 7

Pre-saved programs (disc button)
The IMPRIMO Cure allows you to save frequently used settings as
®
individual programs. The settings for SCHEU-DENTAL`s IMPRIMO LC resins
®
are already pre-saved as well.
Please touch the disc button in the main menu and choose the
desired program. By touching the circle button , the IMPRIMO Cure
®
will start curing the object.
Settings (gear button)
Please touch the gear button in the main menu to access the settings menu. Please use this only in instruction with a SCHEU-DENTAL service
technician. The settings offer you to update your firmware.
5. Technical specifications (IMPRIMO Cure, REF 5625.1)
®
Dual wavelength: 365-405 nm
Light source: UV LED panel
Power: 230 volt, 80 watt
Dimensions: 405 x 210 x 430 mm
Weight: 10 kg
Chamber: 167 x 115 x 105 mm
Software: Linux OS
Network compatibility: Wifi
Sensor: Gas pressure, UV sensor
working pressure: 1.8 bar
Touchpanel: 7"
7
