2.2.3.4 Change Password
To change the PIN code, select this option, press <Left/Right> button to trigger
changing password and <0~9> buttons to enter old password, new password and
confirm new password. If succeed, the PIN Code Changed message will be displayed,
otherwise the PIN Code Error message will be displayed.
2.2.4 Advance Timer
User can set timer for watching the program by date and time manually or from the
TV/Radio Guide(see section 2.3.2). When setting date and start time is arrived,
STB will automatically switch to the wanted program. Press any key except <Vol-
/Vol+/Mute> button, STB asks user to abort it or not when watching booked program.
User can delete the event while it isn't at running.
2.2.5 Set Default
Restore STB to factory default. All settings did by user will be restored to factory
default values and the database will be erased together.
2.2.6 SW Update(Optional)
Note: Not all receivers have this item.
Update software by USB. Enter file browser and press <Left/Right/OK> button to
change folder and focus on the update file, press <OK> button to start update.
2.3 TV/RADIO
There are two types of program: TV and Radio.
The operation of the List and Guide of TV and Radio are almost the same. Herein
take TV as example.
2.3.1 List
User can operate some functions in List. See Figure 5.
2.3.1.1 Favorites
User can quickly channel up/down the favorite programs by favorite filter. There
are 8 groups of favorite for user setting: News, Sport, Movie, Music, Shopping,
Travel, Boy and Girl. Press <1~8> button to set or clear the favorite group when
Favorites option selected.
TV List
All
No. Program Name Status
0001 CT SPORT
0002 Aplikace MHP
0003 CT 1
0004 CT 2
0005 CT 24
0006 NOVA
Favorites Tool
CH+/-
1-8: Favorite Group Edit
Figure 5. TV List
9
01/01/2008 02:19
CH23/490166 KHz
PID:V 1025 , A 1041
Exit
Save
