Operating Instructions MSA 2
When the operator confirms his intent of starting the fusion
process, pressing the START/OK ( I ) button, the unit will start to
weld.
If the barcode is not correct the machine and the scanner give
both a prolonged tone to ask for the correct one. In case of
inconsistency between measured versus scanned parameters
the machine shows instead a message screen, with the proper
error like the following one (fitting resistance too high in respect
to the nominal value).
2.6
Before starting the fusion process, the MSA 2.1 shows a
reminder to the operator, to ensure the preparation activities
have been properly carried out.
As soon as the operator confirms with the START/OK button, the
fusion process starts.
E-10
12/06/12 15:50

Preparation check (MSA 2.1 only)

12/06/12 15:50
Fusion process
25°C
25°C
13
