Pet-Immune Pir Motion Detector - Chuango H4 PLUS Manuel Utilisateur

Pet-immune PIR Motion Detector

The motion detector is designed for use on interior walls and is set to Home Mode
by default. Whenever the sensor detects movement (only while the alarm is armed), a
push notification including the sensor name will automatically be sent to the registered
users, and the hub's internal siren will sound immediately.
LED ON / OFF
Infrared Sensor
Blinks continuously
Blinks once
Blinks once every 3 seconds
Tamper Switch
The tamper switch (small black lever underneath the back bracket) will trigger an
alarm notification if an unauthorized attempt is made to remove the detector from its
installed location.
Detection Area
Top View
1. Detection Window
2. LED indicator
3. Snap Joint
4. Test button
5. Bracket
Infrared Sensor
Tamper Switch
Zone setting
Motion detector is performing a self-test
Motion detected
Low battery indication, please change the battery
immediately
2.5m
Side View
09
