The LEDs display the strength of the received signal. The more
LEDs are lit (from bottom to top), the stronger the signal. If two
LEDs or less are lit, then the signal is not strong enough for
reliable operation. The green power supply LED is always lit.

9. Technical data

Environment class
Security level
Protection class
Operating temperature
Humidity
Dimensions
Weight
Power supply
Power consumption
Frequency
Display
Signals
Tamper monitoring
Wireless transmission
power
Subject to alterations and errors.
II
2 EN50131-1 und -3
IP 54
-10 °C to +55 °C
96% relative humidity
123.9 x 123.9 x 40.7 mm
(W x H x D)
200 g
9-14 V DC, 12 V DC nominal
55 ±5% mA (standby)
600 mA (alarm)
868.6625 MHz
8 LEDs of different colours
Internal piezo signaller
(ca. 90 dB (A) @ 1 m)
No
Max. 10mW
