6. T
ECHNICAL
Dimensions and Weight
Power
Light Source
Laser
Wash LED
Swarm LED
Strobe
Photometrics
Thermal
DMX
Ordering
Page 28 of 124
S
PECIFICATIONS
Length
13.1 in (335 mm)
Note: Dimensions in inches rounded to the nearest decimal digit.
Input Voltage
Switching (internal)
Parameter
Consumption
Operating current
Power linking current (units)
Fuse
Power I/O
Power input connector
Power output connector
Power cord plug
Type
Laser (green)
Laser (red)
Type
LED
Color
Quad-Color RGB+UV
Type
LED
Color
Red
Green
Blue
Amber
White
Type
LED
Color
White
Parameter
Coverage angle (laser)
Coverage angle (Swarm)
Coverage angle (SMD strobe)
Coverage angle (Wash)
Strobe rate
Illuminance @ 2 m (strobe)
Laser Maximum External Temp
95 °F (35 °C)
I/O Connectors
3-pin XLR
Product Name
Swarm Wash FX
Width
13 in (332 mm)
Range
100–240 VAC, 50/60 Hz
120 V, 60 Hz
40 W
0.5 A
8 A (15 units)
T 1.6 A, 250 V
US/Worldwide
IEC
Edison
Edison (US)
Power
30 mW
100 mW
Power
1.5 W
Quantity
8
Power
3 W
Quantity
1
1
1
1
1
Power
1 W
Quantity
12
82°
65°
71°
46°
0–20 Hz
823 lux
Cooling System
Convection
Connector Type
Sockets
Item Code
10051155
Height
9.4 in (241 mm)
Voltage Selection
Auto-ranging
230 V, 50 Hz
8 A (26 units)
T 1.6 A, 250 V
UK/Europe
Local plug
Wavelength
Lifespan
50,000 hours
Current
600 mA
Lifespan
50,000 hours
Current
500 mA
500 mA
500 mA
500 mA
500 mA
Lifespan
50,000 hours
Current
300 mA
Channel Range
UPC Code
781462215033
Swarm Wash FX User Manual (Version 2)
Weight
9.2 lb (4.2 kg)
38 W
0.3 A
IEC
IEC
532 nm
650 nm
18 or 2
