any harmful gases); therefore, it is highly recom-
mended.
It should not be taken for granted that batter-
ies and battery chargers with the same technical
features as those we offer will produce the same
results. Only perfect compatibility between these
elements (Pb-Acid batteries, gel batteries and bat-
tery chargers) will safeguard the performances,
the service life, the safety and the economic value
invested.
5.1.2 BATTERY CHARGER
This type of high-frequency battery charger effi-
ciently charges batteries, extending their operating
and service life. In addition, because they can be
configured, it is a very versatile solution; the same
battery charger can be used for both Pb-Acid bat-
teries and for gel batteries.
It should not be taken for granted that batter-
ies and battery chargers with the same technical
features as those we offer will produce the same
results. Only perfect compatibility between these
elements (Pb-Acid batteries, gel batteries and bat-
tery chargers) will safeguard the performances,
the service life, the safety and the economic value
invested.
5.2 STRUCTURE AND FUNCTIONS
5.2.1 MACHINE
Photo A
1 Recovery tank
2 Operator's seat
3 Solution tank
4 Rear wheel
5 Bumper wheel
6 Splash guard
7 Traction control pedal
8 Squeegee lifting/lowering lever
9 Steering wheel
Photo B
1 Recovery water tank drain hose
2 Recovery water tank drain hose plug
3 Solution water tank filling plug
4 Suction hose
5 Suction hood and access to the
recovery tank
Photo C
1 Blinker
2 Suction hood
3 Suction filter
4 Recovery tank
Photo D
1 Solution water tank drain plug
Photo E
1 Squeegee bumper wheels
2 Squeegee blades replacement knobs
3 Squeegee fast fixing knob
4 Squeegee inclination adjusting knob
5 Suction hose
6 Squeegee pressure fixing knobs
7 Squeegee wheels
Photo F
1 Solution water filter
Photo G
1 Battery compartment with 6V batteries
2 On- board battery charger
3 Battery charger plug
4 Battery connection diagram
Photo H
1 Detergent solution ouflow adjusting lever
2 Battery security connector
2 Brush plate lifting/lowering lever
Photo I
1 Battery charger cover
2 Red LED - Battery discharged
3 Green LED - Full charged battery
4 Dip-Switches
5 Plastic cap to access the Dip-Switches
6 Dip-Switches for PB-Acid/GEL battery
setting
7 Table with Dip-Switch settings for
PB-Acid/GEL charging curve
Photo L
1 Unblocking lever of the electromechani-
cal brake in working position
(brake applied)
2 Unlocked position of the
electromechanical brake
Photo M
1 Steering wheel
2 Control panel with display
3 General ON/OFF key switch
4 Detergent tank
Photo N
1 Brush motor operating push button
2 Suction motor operating push button
3 Detergent outflow adjusting push button
4 Forward/reverse traction push button
selector
5 Traction speed increase push button
6 Traction speed reduce push button
7 Operating informations display
Photo O
Percentage of dilution of the detergent
1 Dilution with half outflow of clean water
2 Dilution with complete outflow of clean
water
