15
13
12
3
14
3
6
11
LET.
MODIFICATION
2
8
9
DATE
INT.
4
5
1
7
3
MACHINE
PART
ITEM
MAT.
005B0266
ITEM
PART #
DESCRIPTION
1
002B0025 PLEXI COVER
2
004A0021 COVER HINGE ASSEMBLY
3
051-0740 WASHER 1/4" FLAT S/S
4
051-0255 BOLT 1/4-20 x 1-3/4" HEX SS
5
001A2919 WASHER 0.381``ID X 1.062``OD X 3
6
051-0581 NUT 1/4"-20 NYLON LOCK S/S
7
051-0288 BOLT 1/4-20 x 3 1/2" S/S
8
076-0010 "O" RING 1/4" x 3/8" x 1/16"
9
002-0026 UPPER SEAL BAR SPACER
10
004B0173 UPPER SEAL BAR PRE-ASS`Y
11
179-0005 NEOPRENE SPONGE 3/8" O.D. 2042mm
(6.7')
12
002-0024 HINGE BLOCK
13
051-0232 SCREW 1/4-20x 1-1/4"SKT CAP SS
14
051-0580 NUT 1/4"-20 S/S
15
058-0030 NYLON SPACER 3/8IDx3/4ODx1/16
10
DEPT. TOL.
METRIC
300 & 350
USINAGE
± 0.1
TOLERIE
± 0.5
SOUDAGE
± 0. 5
COVER ASSEMBLY
CNC
DWG BY
DATE
S.L.
13-11-26
DATE
APP. BY
QT.
1
1
10
4
4
4
2
2
2
1
1
2
4
4
4
INCH
SIPROMAC
± 0.004"
± 0.020"
± 0.020"
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
N.T.S.
DEPT.
QTY.
M-(M)
1
NO.
005B0266
