1
A
2
DETAIL A
LET.
MODIFICATION
DATE
INT.
005D0596
ITEM
PART #
1
004A4147 MACHINE ASSEMBLY
2
005B1031 STAND ASSEMBLY 19" (OPTION)
3
125-1021 BUSCH KB-0020 220-240V/1PH/50-60HZ
4
114-2009 SILENCER 1/2 NPT TOPRING
6
005A1420 SOFT AIR OPTION
8
005A1355 SEAL BAR ASSEMBLY W/SUPP. TWIN SEAL
9
005A1356 SEAL BAR ASSEMBLY W/SUPP. BAG CUT
10
125-1020 BUSCH KB-0020 115V/1PH/60HZ
6
INSTALLER SUR LA VALVE LORS
4
DE L'OPTION SOFT AIR
3 10
MACHINE
300
PART
MACHINE ASSEMBLY WITH OPTION
ITEM
CNC
DWG BY
MAT.
S.L.
APP. BY
DESCRIPTION
QT.
1
1
1
1
1
1
1
1
DEPT. TOL.
METRIC
INCH
SIPROMAC
USINAGE
± 0.1
± 0.004"
TOLERIE
± 0.5
± 0.020"
SOUDAGE
± 0. 5
± 0.020"
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
N.T.S.
DEPT.
QTY.
M-I
1
DATE
NO.
13-11-22
005D0596
DATE
