Sipromac 300 Manuel D'utilisation page 19

9
4
15
A 001B6619 WAS 001A6619, 008A2051 ADDED 15-01-05 SBU
LET. MODIFICATION
ITEM PART #
13 051-0721 WASHER #8 (4mm) LOCK S/S
14 058-0130 CPVC SPACER #8 x 3/8" OD x 3/8"
15 114-0260 VACUUM GAGE W/ SUPPORT
16 179-0004 NITRILE 1/2'' X 1/8'' AUTOCOLLANT X
1220mm long
8
16
3
10
1
7
DATE INT.
DESCRIPTION
12
11
1
11
13
5
14
005A1446
QT. ITEM PART #
4 1 001-1869 VACCUM GAGE FIXATION RING
4 2 001B6619 MC-05 PANEL
1 3 003A0408 CONTROL INSERT REWORK
1 4 008A2051 MC-05 STICKER
5 033-0046 MICROPROCESSOR MC-05 120 VOLTS
6 033-0047 MICROPROCESSOR MC-05 220 VOLTS
7 033-0110 KNOB FOR POTENTIOMETER
8 033-5000 TOGGLE SWITCH AC/DC ON/OFF
9 051-0109 SCREW #8-32 X 1/2" FLAT PHIL S/S
10 051-0121 SCREW #8-32 X 1" FLAT PHIL S/S
11 051-0550 NUT #8-32 SS
12 051-0720 WASHER #8 FLAT S/S
MACHINE
300, 300D, 400
PART
MC-05 CONTROL ASSY
ITEM CNC
DWG BY
MAT. SBU
APP. BY
DESCRIPTION QT.
1
1
1
1
1
1
2
1
4
4
8
4
6 220V
5 120V
DEPT. TOL. METRIC INCH
SIPROMAC
USINAGE ± 0.1 ± 0.004"
TOLERIE ± 0.5 ± 0.020"
SOUDAGE ± 0. 5 ± 0.020"
ST-GERMAIN DE GRANTHAM
QUEBEC CANADA
N.T.S.
DEPT. QTY.
M
1
DATE NO.
14-02-10
005A1446
DATE
