Write purchased model number here.
Table of Contents:
Warranty .............................................................................. Page 2
MultiChoice Rough-In Installation Instructions ................... Pages 3 - 5
®
13/14 Series Installation Instructions ................................... Pages 6 - 10
Maintenance ........................................................................ Page 11
Cartridge Summary References .......................................... Page 12
To order replacement parts, visit www.deltafaucet.com
!
WARNING:
set by the installer to ensure safe, maximum
temperature. Any change in the setting may
raise the discharge temperature above the limit
considered safe and may lead to hot water
burns.
NOTICE TO INSTALLER: CAUTION!–As the
installer of this valve, it is your responsibility
to properly INSTALL and ADJUST this valve
per the instructions given. This valve does
not automatically adjust for inlet temperature
changes, therefore, someone must make the
necessary Rotational Limit Stop or temperature
knob adjustments at the time of installation and
further adjustments may be necessary due to
seasonal water temperature change. YOU MUST
inform the owner/user of this requirement by
following the instructions. If you or the owner/
user are unsure how to properly make these
adjustments, please refer to pages 8 and 9, and if
still uncertain, call us at 1-800-345-DELTA.
After installation and adjustment, you must affix
your name, company name and the date you
adjusted the Rotational Limit Stop or temperature
knob to the caution label provided and apply or
attach the label to the back side of the closest
cabinet door and the warning label to the water
heater. Leave this Instruction Sheet for the
owner's/user's reference.
www.deltafaucet.com
You May Need
This system/device must be
MultiChoice
Installation Instructions
Owners Manual
13/14
Series
!
WARNING:
or thermostatic bath valve is designed
to minimize the effects of outlet water
temperature changes due to inlet
pressure changes, commonly caused by
dishwashers, washing machines, toilets
and the like. It may not provide protection
from hot water burns when there is a
failure of other temperature controlling
devices elsewhere in the plumbing system,
if the rotational limit stop or temperature
knob is not properly set or if the hot water
temperature is changed after the settings
are made or if the water inlet changes due
to seasonal changes.
Do not install a shut-off device on either
outlet of this valve. When this type of
device shuts off the water flow, it can
defeat the ability of the valve to balance
the hot and cold water pressures and
could increase the risk of a burn injury.
1
Valve Trim
®
This pressure balanced
5/15/18 Rev. G
