Low-Cut Switch
The Low-Cut Switch is located on the front-right side of the
microphone, and inserts a low-cut filter at 80Hz (left
position) or 160Hz (right position). The switch's center
position removes the filter for a flat frequency response.
Wind noise, plosives, footfall noise or rumble might affect
the recorded signal, so enabling the low-cut filters reduces
such unwanted noise and prevents distortion. Additionally,
the low-cut filters also minimize the proximity effect when
recording sound sources at a very short distance.
Powering
To ensure proper operation, the microphone requires a phantom power source providing 48 Volts

Safety and maintenance

Cleaning the microphone
After every use, clean the microphone with a dry, soft cloth tissue and store it in a solid case or a
zipper pouch.

Technical Specifications

Capsule
Polar patterns
Frequency range
Sensitivity
Max. SPL (0.5% THD)
Equivalent noise level
Dynamic range
according to IEC 61938.

Risk of damage

Do not connect the microphone to any power supply other than a
phantom power source (input with phantom power or external IEC
standard phantom power supply) with a floating connector, using a
balanced cable with studio grade connectors to IEC 268-12 only. This
is the only way to ensure safe and reliable operation.
Risk of damage
Please make sure that the piece of equipment to which your
microphone will be connected fulfils the safety regulations enforced in
your country and is fitted with a ground lead.
Hand-crafted 1" true condenser capsule
Cardioid
20 – 20,000 Hz
30 mV/Pa (-30.5 dBV)
140 / 150 / 160dB
9 dB(A)
131 / 141 / 151 dB (0/10/20 dB Attenuation pad)
(0/10/20 dB Attenuation pad)
SPL
