OPERATING INSTRUCTIONS
USB microscope camera 1.3
25 x and 60 x
Item-No. 19 13 12
Use in accordance with manufacturer's instructions
The product is a camera designed to transfer recorded images via a USB port to a PC.
Thanks to the integrated lens, particularly small objects/surfaces can be magnified and imaged.
The power is supplied via a USB port.
This product complies with the applicable national and European requirements. All names of
companies and products are the trademarks of the respective owner. All rights reserved.
Package Contents
• Camera with permanently attached USB cable
• CD with software
• Operating Instructions
Safety Instructions
The warranty will be void in the event of damage caused by failure to observe
these safety instructions! We do not assume any liability for any resulting
damage!
Nor do we assume liability for damage to property or personal injury caused by
improper use or failure to observe the safety instructions. The warranty will be
void in such cases.
• The unauthorised conversion and/or modification of the product is inadmissible for
safety and approval reasons (CE).
• Attention, LED light! Do not look directly into the LED light! Do not look into the
beam directly or with optical instruments!
• The product is not a toy and should be kept out of the reach of children.
• Do not leave packaging materials unattended. They may become dangerous
playthings for children.
• The product should be used only in dry indoor areas; it must not be exposed to
damp or wet!
• Handle the product with care; it can be damaged by impacts, blows, or accidental
drops, even from a low height.
Driver/Software Installation
• Start your operating system. Place the CD included in the delivery in an appropriate drive on
your computer.
• The software now starts automatically and you can install the drivers/software. If the CD does
not start automatically, you have to start the installation program on the CD manually.
Follow the program's instructions.
• After installation of the driver/software connect the USB plug of the camera to a free USB2.0
port of your computer. The operating system recognises the new hardware and completes
the driver installation.
• Start the software.
Operation
• Move the front side of the camera as close as possible to the desired object (e. g. place the
front side on a daily newspaper). The maximum distance to the object is about 4 cm.
• Set a sharp, focused image using the adjustment wheel. The LEDs for object lighting may be
switched on and off by a small thumb wheel on the USB cable.
Due to the optics used the image can be focused in two magnification levels (see
technical data). To do this, move the adjustment wheel in one direction or the other
until the image is focused.
Do not overwind the adjustment wheel. Turn the adjustment wheel slowly, so that you
can focus the picture accurately.
The LED light can cause pictures or reflections that are too bright on reflective
surfaces or objects.
• Rotate the camera, if necessary, until the picture is adjusted in accordance with your needs.
• Make sure no objects touch the lens as they might damage it. Do not touch the optics (the lens
will get dirty).
• Using the button on the upper end of the microscope camera, the current image can be photo-
graphed; for this purpose, the software provided must be started.
Handling
Version 03/11
The product is to be used in dry indoor locations only. Do not expose it to dampness
°
or moisture.
Never use the product immediately after it has been taken from a cold room into a
warm one. The condensation that forms might destroy your unit.
Allow the product to reach room temperature. This may take several hours.
The following unfavourable conditions are to be avoided when installing or trans-
porting the product:
- Damp or excess air humidity
- Extreme cold or heat
- Dust or flammable gases, fumes or solvents
- Strong vibrations
- Strong magnetic fields such as those found close to machinery or loudspeakers
When setting up/operating the product, ensure that the cables are not bent, over-
wound or squeezed.
Cleaning
If required, clean the optics from dust and dirt. Use an appropriate lens cleaning system, e. g. a
clean, soft brush. Do not press too hard on the optics/mechanics of the camera, since it may be
damaged. Furthermore, you may cause scratch marks on the lens.
Disposal
Dispose of an unserviceable product in line with the relevant statutory regulations.
Technical Data
Operating voltage ........................5 V/DC (via USB)
Sensor ..........................................CMOS, 1280 x 1024 Pixels
USB Connection ..........................USB2.0/1.1
Lighting ........................................4 white LEDs
Magnification approx.....................25x or 60x
Dimensions (Ø x L) approx.: ........31 x 93 mm
Weight approx...............................85 g
These operating instructions are a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data pro-
cessing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in technology and equipment reserved.
© Copyright 2011 by Conrad Electronic SE.
