Specifications
Specifications
Picture Tube
Input Signal
Display Colours
Synchronisation
Range
Resolutions
Active Display
Area (Factory
Setting)
Active Display
Area (Full Scan)
Rated Voltage
Rated Current
Dimensions
Weight
53 cm (21 inch) flat square CRT, 50.8 cm (20 inch)
viewable image size, 0.28 mm dot pitch, Medium-Short
persistence phosphor, semi tint screen, multi-layered,
anti-static OptiClear coating
Analog 0.7 Vp-p 75 Ω Positive
Video
Sync Separate sync.
Horizontal sync.
Vertical sync.
Composite sync.
Analog Input: Unlimited colours
(Depends on the graphics board)
Horizontal 31 kHz to 82 kHz (Automatically)
Vertical 55 Hz to 120 Hz (Automatically)
Maximum 1280 x 1024 (75 Hz non interlaced)**
Recommended 1024 x 768 (85 Hz non interlaced)*
Horizontal 390 mm (Active display area is
dependent upon the signal timing)
Vertical 293 mm (Active display area is
dependent upon the signal timing)
Horizontal 402 mm (Active display area is
dependent upon the signal timing)
Vertical 301 mm (Active display area is
dependent upon the signal timing)
AC 220-240 V 50/60 Hz
1.3 A
509 (W) x 519 (H) x 560 (D) mm
33.7 kg
E - 19
TTL Level
Positive/Negative
Positive/Negative
TTL Level
Positive/Negative
