Part names and functions

Top panel

1 iPod/iPhone connector port
To connect the iPod/iPhone, press the PUSH OPEN tab
(page 15).

Display

1
Lights when the sound is muted.
Note
• The mute icon will be displayed in red.
2
Start playback.
3
Pause playback.
1
PUSH OPEN
1 2 3
 
5
4
Timer function is set.
5 Character display
Displays various system information.
4
