Converting Appliance For Use With Lp Gas - Forza FR304GN Manuel D'installation

Converting Appliance for Use with LP Gas

Conversion is to be performed by an AUTHORIZED SERVICER (or other qual-
ified agency) in accordance with the manufacturer's instructions and all codes
and requirements of the authority having jurisdiction. Failure to follow instruc-
tions could result in serious injury or property damage. The qualified agency
performing this work assumes responsibility for this conversion.
WARNING: Electrical power and gas must be turned off prior to conversion.
If this appliance is to converted for use with gas LP (propane or butane), each of the following modifications must be
performed:
Replace Injectors (two ring flame burner)
1) Remove the grates and burner caps.
2) Remove brass gas spreader.
3) Remove finjector (A) by usfing a 9-32" nut drfiver counter cflockwfise.
4) Remove finjector (B) by usfing a 9-32" box wrench counter cflockwfise.
5) Install the injectors supplied with this appliance in the appropriate burner. The injectors have small numbers stamped on
the side, this number corresponds with the orifice diameter and its correct burner location (refer to illustrations in
the section: "Injectors Position").
6) Turn clockwise to tighten (tighten to a torque of 15 to 20 inch-lbs).
7) Replace all parts following the reverse order.
8) Save the injectors removed from the appliances for future use.
27
EN
