E N
3. I N S TA L L ATI O N I N A WA L L
• It is possible to install the unit in a wall. For better ventilation, an opening
depth of 235 mm is suggested. Construct the opening according to the
specifications below.
S K U
EF42C
EF43C
EF44C
EF45C
• Prepare the opening and the diffuser, place the unit carefully into the
framed opening and no fixing brackets are required.
NOTE: If the existing opening is slightly narrower, the handles on both
sides can be removed.
W I DT H H E I G H T
580–610 5 15 –5 4 0
660–690 5 9 5 –6 2 0
760–790 5 9 5 –6 2 0
840–870 6 5 5 –6 8 0
D E P T H (R E C O M M E N D E D)
≥ 235
≥ 235
≥ 235
≥ 235
