Shotmaster S-Pro/M-Pro/St - Eversys Enigma Shotmaster E'2ct/Classic Mode D'emploi

2 Description

2.3.15 Shotmaster s-pro/m-pro/ST

Shotmaster m-pro/ST
Technical data
Brew chamber 4 x 24 g
Grinder 4 x Ceramic burrs - 64 mm
User Interface 3 x Touch screen
256 mm (10.1")
Bean hopper 4 x 1.5 kg
Coffee outlet height* 190 mm max.
Hot water outlet 160 mm max. or
height* 215 mm max. (option)
Interface 4 x USB, 2 x Ethernet,
2 x CCI/CSI
Cup heater surface Up to 64 espresso cups
Coffee boiler size 4 x 1.5 L
Steam boiler size 5.4 L
Grounds drawer 2 x 700 g
Drip tray Large with pitcher rinsers or
Standard (option) or Large
(option)
Water Connection
Water hose Inox braided pipe G3/8"
female x 2 m
Drain hose Ø 22 mm x Ø 16 mm x 2 m
*measured from the drip tray
849 mm (33.4 in)
Fig. 2-19
40/ 132
Super Traditional
Weight
Performance (up to)
Espresso / h (23 s)
Hot water / h (200 ml)
Cappuccino / h (23 s)**
Adjustable hot water temperature (Manual)
Adjustable hot water temperature (Automatic)
e'Foam Micro Air Dosing (MAD) system
(controlled electronically)
Milk system with EMT (Electronic Milk Texturing)
Voltage / Power
Power consumption (standby mode)
2/PE, 208V~, 60Hz, 30A 1/N/PE, 220-240V~, 50/60Hz, 25A 1/N/PE, 220-240V~, 50/60Hz, 25A 2/PE, 200V~, 50/60Hz, 30A - JP 1/N/PE, 220-240V~, 50/60Hz, 25A 2/PE, 208V~, 60Hz, 30A
2 x 1/N/PE, 220-240V~, 50/60Hz, 25A 2 x 1/N/PE, 220-240V~, 50/60Hz, 25A 1/N/PE, 220-240V~, 50/60Hz, 25A 2 x 1/N/PE, 220-240V~, 50/60Hz, 25A 1/N/PE, 220V~, 60Hz, 25A - KR
2 x 1/N/PE, 220-240V~, 50/60Hz, 25A 3/N/PE, 380-415V~, 50/60Hz, 16A 3/N/PE, 380-415V~, 50/60Hz, 16A 3/N/PE, 380V~, 60Hz, 16A - KR 3/N/PE, 380-415V~, 50/60Hz, 16A
3/PE, Δ 220-230 V~, 50/60 Hz, 20A 1/N/PE, 220-240V~, 50/60Hz, 25A - ZH 3/PE, Δ 220-230 V~, 50/60 Hz, 20A - BE/NO
2 x 1/N/PE, 220-240V~, 50/60Hz, 25A - ZH
3/N/PE, 380-415V~, 50/60Hz, 16A - ZH
Water pressure and flow
2.5 - 4 bars (36.3 - 58 psi) If the pressure exceeds 4 bars (58 psi), it is
necessary to install a pressure valve reducer.
If the main flow rate is under 200 L/h (left hand side) and 150 L/h (right
hand side), there is a risk of damaging the water pump.
**milk is dispensed through the 1.5-Step
Select your region:
Asia
Central - South
America
Europe
Shotmaster
s-pro
163 kg
-
-
Less than 2 W
4600 + 4600 W 4600 + 4600 W 5600 + 5600 W 5600 + 5600 W 6000 + 4300 W 5600 + 5600 W
10200 + 5600 W 10200 + 5600 W 10200 + 5600 W 5600 + 5600 W 5100 + 5100 W
10200 + 5600 W 7900 + 5600 W 7900 + 5600 W 7900 + 5600 W 7200 + 5100 W
5600 + 5600 W 5600 + 5600 W 5600 + 5600 W
10200 + 5600 W
7900 + 5600 W
667 mm (26.2 in)
717 mm (28.2 in) with large drip tray
Enigma Mode d'emploi
Oceania
North
America
Middle
East
Shotmaster
m-pro
167 kg
700
170
350
Yes
Option
Yes
Yes
| © Eversys S.A.
