2.3.12 Shotmaster s/m/Classic

Shotmaster m/Classic
Technical data
Brew chamber
Grinder
User Interface
Bean hopper
Coffee outlet height* 190 mm max.
Hot water outlet
height*
Interface
Cup heater surface
Coffee boiler size
Steam boiler size
Grounds drawer
Drip tray
Water Connection
Water hose
Drain hose
*measured from the drip tray
Fig. 2-16
5700109748 | V01-09/2021
2 x 24 g
2 x Ceramic burrs - 64 mm
1 x Touch screen
256 mm (10.1")
2 x 1.5 kg
160 mm max. or
215 mm max. (option)
2 x USB, 1 x Ethernet,
1 x CCI/CSI
Up to 64 espresso cups
2 x 1.5 L
5.4 L
1 x 700 g
Large with pitcher rinsers or
Standard (option) or Large
(option)
Inox braided pipe G3/8"
female x 2 m
Ø 22 mm x Ø 16 mm x 2 m
560 mm (22 in) 560 mm (22 in)
Select your colour:
Earth
Tempest
Classic
Weight
Performance (up to)
Espresso / h (23 s)
Hot water / h (200 ml)
Cappuccino / h (23 s)
Adjustable hot water temperature (Manual)
Adjustable hot water temperature (Automatic)
e'Foam Micro Air Dosing (MAD) system
(controlled electronically)
Milk system with EMT (Electronic Milk Texturing)
Voltage / Power
Power consumption (standby mode)
2/PE, 200V~, 50/60Hz, 30A - JP 1/N/PE, 220-240V~, 50/60Hz, 25A 2/PE, 208V~, 60Hz, 30A 2/PE, 208V~, 60Hz, 30A 1/N/PE, 220-240V~, 50/60Hz, 25A 1/N/PE, 220-240V~, 50/60Hz, 25A
1/N/PE, 220-240V~, 50/60Hz, 25A 1/N/PE, 220V~, 60Hz, 25A - KR 2 x 1/N/PE, 220-240V~, 50/60Hz, 25A 2 x 1/N/PE, 220-240V~, 50/60Hz, 25A 2 x 1/N/PE, 220-240V~, 50/60Hz, 25A
3/N/PE, 380V~, 60Hz, 16A - KR 3/N/PE, 380-415V~, 50/60Hz, 16A 2 x 1/N/PE, 220-240V~, 50/60Hz, 25A 3/N/PE, 380-415V~, 50/60Hz, 16A 3/N/PE, 380-415V~, 50/60Hz, 16A
3/PE, Δ 220-230 V~, 50/60 Hz, 20A 1/N/PE, 220-240V~, 50/60Hz, 25A - ZH 3/PE, Δ 220-230 V~, 50/60 Hz, 20A - BE/NO
2 x 1/N/PE, 220-240V~, 50/60Hz, 25A - ZH
3/N/PE, 380-415V~, 50/60Hz, 16A - ZH
Water pressure and flow
2.5 - 4 bars (36.3 - 58 psi) If the pressure exceeds 4 bars (58 psi), it is
necessary to install a pressure valve reducer.
If the main flow rate is under 200 L/h, there is a risk of damaging the water
pump.
**milk is dispensed through the 1.5-Step
650 mm (25.6 in) with large drip tray
Description 2
Select your region:
Asia
Central - South
America
Europe
Shotmaster
s
91 kg
-
-
Less than 2 W
600 mm (23.6 in) 600 mm (23.6 in)
Oceania
North
America
Middle
East
Shotmaster
m
95 kg
350
170
350
Yes
Option
Yes
Yes
4600 W 6000 W 4600 W 5600 W 5600 W 5600 W
10200 W 10200 W 10200 W 5600 W 5100 W
10200 W 7900 W 7200 W 7900 W 7900 W
5600 W 5600 W 5600 W
10200 W
7900 W
37/ 132
