SYSTEM

Part 1: General

1.1 Description
A. The Haier Advanced heat pump air conditioner shall be a variable capacity mini-split type system comprised of
a single outdoor and a single wall-mounted indoor unit.
1.2 Toxicity
A. The heat pump system shall participate in RoHS compliance and should be listed in the directory.

Part 2: Performance and Operating Range

2.1 Operating Range
A. The heat pump shall provide cooling temperature range of 14°~115°F (-10°C~46°C)
B. The heat pump system shall be capable of providing greater than 70% capacity at -4°F (-20°C) outdoor ambient
temperature.
C. The heat pump system shall be capable of 100% rated heating capacity at 20°F (-6°C) outdoor ambient
temperature.
D. The heat pump shall operate normally with voltages between 187~253V.
2.2 Performance
The system shall perform within the specified operating window found on the following table.
A. Cooling performance rating shall be verified following AHRI 210/240 standards of 80°F db/67°F wb (27°/19°C)
indoor temperature and 95°F db/75°F wb (35°/24°C) outdoor temperature.
B. Heating performance rating shall be verified following AHRI 210/240 standards of 70°F db/60°F wb (21°/16°C)
indoor temperature and 47°F db/43°F wb (8°/6°C) outdoor temperature.
