Checking the Contents
of the Packing Box

Recirculation Cooling Unit

Placing Unitom-5

2
Unitom-5
Instruction Manual

1. Getting Started

In the packing box you should find the following parts:
1 Fork spanner (30 mm), for changing the cut-off wheel
1 Grease gun, for lubrication of tilting frame bearings
2 Cover plugs for threads for cutting tables
1 Set of Instruction Manuals
1 PVC hose 1/2", 2 m
1 Outlet hose, 2 m
1 Drain elbow pipe
5 Hose clamps
Unitom-5 should be placed on the optional Struers table
(LABUL), or a table which is able to carry a weight of min.
200 kg.
Adjust the table height using the screws in the table legs. It is
important that the table and Unitom-5 are level. Place Unitom-5
on the table. If the machine is not horizontal, you must adjust the
height for each corner, as follows:
Loosen the upper 13 mm nut under the corner screw.
Adjust the lower 8 mm nut with a spanner.
Fasten the upper 13 mm nut again.
Repeat the adjustment for each of the other three corners
until Unitom-5 is levelled.
