Dimensions
Content of package:
1x Alarm device
1x Diaphragm nipple M20
1x Operating instruction
1x Resistor (only –SSM)
Technical Data
Flash energy
Rated effective luminous
intensity
Flash frequency
Rated voltage
Operating voltage range
Current consumption
(max)
Power consumption
Duty cycle
Connection terminal
Protection system
Protection class
Operating temperature
Storage temperature
Max. rel. Humidity
Cable entry
Sealing range of
grommet
Material of housing
Material of lens
Installation position
Options
Accessory
Lens colours
Approvals
Approvals
(valid for marked equipment)
Construction Product
VdS 0786-CPD-21219
Directive
(89/106/EWG)
VdS
G212186, data see Construction Product Directive (89/106/EWG)
GL
61062-13 HH
Rated Voltage
115V AC
230V AC
UL, cUL
24V AC
12V DC
24V DC
48V DC
PYRA Xenon beacons PY X-S-05 comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules
085 501 949j
PY X-S-05 – Beacon
Operating and installation instruction
109.6 [4.31]
98 [3.86]
37 [1.46"]
prepared
M20 piercing
12 V DC
24V DC
10 –15 V DC
18 – 30 V DC
700 mA
360 mA
7,5 W
9,5 W
With the use of cable diameters <7 mm, a cable screw joint
Options
Rated voltage
Operating voltage range
acc. to EN54-23
Lens colours
Signalling area
Environmental
protection class
Installation position
The test was performed using the provided diaphragm nipples and the outer fixing holes.
Environmental Category C, H, EMC1
Visual Signal Appliance - General Signaling Equipment - UEES, UEES7
Suitable for indoor and outdoor use.
Warning: Not to be used as a Visual Public Mode Alarm Notification Appliance.
According to CSA-C22.2 No. 205-M1983 clause 4.3.4 the connection is limited to max.
three leads.
80.6 [3.17]
5J
44 cd (clear)
1Hz
48V DC
40 – 57 V DC
18 – 30 V AC
170 mA
7,5 W
100%
0,14 - 2,5mm² / AWG24 - AWG 14 (stranded)
IP66 (EN60529), Type 4 & 4x
II
Double insulated equipment
-40° C...+55° C
-40° C...+70° C
90%
4x M20 (prepared)
7 – 13 mm
with sufficient ingress protection must be provided
PC/ABS Blend
PC
arbitrary
-SSM (see page 4)
Sealing plug (Art-no. 28300000002)
clear, white, yellow, amber, red, green, blue
–SSM (24V DC only)
24V DC
18V – 30V
EN 54-23 Category O: see document 30320-005-1
see document 30303-005-1
30320-004j
26.8 [1.06"]
44.1 [1.74"]
22 [0.87"]
24V AC
115 V AC, 50/60
50/60 Hz
Hz
95 - 127
V AC
800 mA
120 mA
30 VA
14,5 VA
48V DC
40 – 57V DC
red, clear
Type B
50 [1.97"]
35.4
[1.39"]
Hole pattern in the
inside of housing
230V AC
50/60 Hz
195 – 253 V AC
90mA
21,5 VA
3
