SERVICE PARTS

MODEL PSBF66W
NOTE: NOT ALL PARTS AVAILABLE. FOR
QUESTIONS CONTACT MANUFACTURER.
7
31
12
6
19
2
5
NO. P/N DESCRIPTION
1 66632 Top Cover
2 66633 Door
3 n/a Hopper
4 n/a Main Body
5 66634 Ash Pan
6 n/a Decorative Plate
7 66635 Left Side Panel
8 66636 Right Side Panel
9 66622 Silicone Rubber Sealing Ring
10 66615 Power Socket
1 1 66637 Motherboard
12 66638 Fire Pot
13 66639 Vacuum Switch
14 66640 Igniter
Cleveland Iron Works Wood Pellet Fire Stove
1
20
15
33
28
34
14
27
29
4
26
19
NO. P/N
15 66641
16 66612
17 66642
18 66643
19
20 66644
21 66645
22 66646
23 66647
24 66648
25 66620
26
27 66649
28 66650
17
3
36
24
9
35
32
11
28
30
31
29
8
DESCRIPTION
Combustion Blower
Circulation Blower
Rear Cover
Room Sensor
n/a Flue Sealing Plate
Display Panel
Pressure Device Silicone Tube
Rear Sealing Plate
Right Side Panel Hinge
Blower Bracket
Blower Fixed Plate
n/a Fireproof Plate
Door Hinge
Rear Cover Fixed Plate
28
22
18
10
21
13
23
25
16
WARNING: FAILURE TO
POSITION THE PARTS IN
ACCORDANCE WITH THESE
DIAGRAMS OR FAILURE
TO USE ONLY PARTS
SPECIFICALLY APPROVED
WITH THIS STOVE MAY
RESULT IN PROPERTY
DAMAGE OR PERSONAL
INJURY.
NO. P/N DESCRIPTION
29 66651 Ash Pan Lock Parts
30 n/a
31 66652
32 66653
33 66654 Temperature Sensor
34 66655
35 66656
36 66657 Left Side Panel Hinge
37 66658 Remote (not shown)
38 66659
39 66660
Operating Instructions and Owner's Manual
39
38
Ground Screw
Magnet
Door, Latch
Safety Sensor
Socket Fixed Plate
Accessory Kit
Auger Assembly
