Installation
6 Install the Light Bulbs
To prevent possible OVERHEATING of the end panel or light socket:
Use ONLY A19 incandescent (100W maximum) or compact fluorescent (26W maximum) light bulbs.
l
DO NOT use incandescent bulbs larger than 100W.
l
DO NOT use compact fluorescent light bulbs larger than 26W (100W equivalent).
l
DO NOT use halogen bulbs.
l
DO NOT use short neck or specialty light bulbs.
l
1. Pull on the top center of the light lens and rotate the light lens down.
2. Insert an A19 incandescent (100W maximum) or compact fluorescent (26W, 100W equivalent) light bulb
into the light socket.
NOTE: DO NOT use halogen, short neck, or specialty light bulbs as these may overheat the end panel or
light socket. DO NOT use LED bulbs as they may reduce the range or performance of your
remote control(s).
3. Rotate the lens up to close.
or
7 Attach the Emergency Release Rope and Handle
NOTE: If it is necessary to cut the emergency release rope, seal the cut end with a match or lighter to prevent
unraveling. Ensure the emergency release rope and handle are above the top of all vehicles to avoid entanglement.
or
14
To prevent possible SERIOUS INJURY or DEATH from a falling door:
If possible, use emergency release handle to disengage trolley ONLY when door is CLOSED. Weak or
l
broken springs or unbalanced door could result in an open door falling rapidly and/or unexpectedly.
NEVER use emergency release handle unless doorway is clear of persons and obstructions.
l
NEVER use handle to pull door open or closed. If rope knot becomes untied, you could fall.
l
1. Insert one end of the emergency release rope through the handle. Make sure that "NOTICE" is right side
up. Secure with an overhand knot at least 1" (2.5 cm) from the end of the rope to prevent slipping.
2. Insert the other end of the emergency release rope through the hole in the trolley release arm. Mount the
emergency release within reach, but at least 6 feet (1.83 m) above floor, avoiding contact with vehicles to
prevent accidental release and secure with an overhand knot.
Trolley
Release Arm
