8.1

Technische gegevens

Technical Data for Pleasure Craft Duty
Based on engine power B to DIN 6270; shock factor
K = 1.25 to be applied, if engine has 1 cylinder / K = 1.20 for 2 cylinders / K = 1.15 for 3 cylinders
MODEL RATIO
«A» Pos «B»Pos
ZF 5 M 2.045 1.864
2.722 2.150
K = 1.25 to be applied, if engine has 1 cylinder / K = 1.20 for 2 cylinders / K = 1.15 for 3 cylinders
MODEL RATIO
«A» Pos «B»Pos
ZF 6 M 2.045 1.864
2.722 2.150
K = 1.25 to be applied, if engine has 1 cylinder / K = 1.20 for 2 cylinders / K = 1.15 for 3 cylinders
** Max. 95 Nm (70 ft lb) admissible for main travelling direction with gear lever set to «B»
MODEL RATIO
«A» Pos «B»Pos
ZF 10 M 1.482 1.864
1.792 1.864
2.045 1.864
2.722 2.150
K = 1.25 to be applied, if engine has 1 cylinder / K = 1.20 for 2 cylinders / K = 1.15 for 3 cylinders
MODEL RATIO
«A» Pos «B»Pos
ZF 12 M 2.136 1.955
2.632 1.955
K = 1.25 to be applied, if engine has 1 cylinder / K = 1.20 for 2 cylinders / K = 1.15 for 3 cylinders
** Max. 120 Nm (88.5 ft lb) admissible for main travelling direction with gear lever set to «B»
MODEL RATIO
«A» Pos «B»Pos
ZF 15 M 1.556 1.955
1.875 1.955
«A» POS = continuous running position (normally AHEAD).
«B» POS = reverse position.
B/W = Borg Warner adaptor.
Note = For all «M» (Mechanical) transmissions reduce power capacity by the following shock factors: 1 cylinder engine ÷ 1.25, 2 cylinder engine ÷ 1.20, 3 cylinder engine ÷ 1.15.
58
Plus d'informations sur : www.dbmoteurs.fr
Gebruik en onderhoud ZF 4-1 M / ZF 30 M
POWER / RPM INPUT POWER CAPACITY
kW hp kW hp kW
2800 rpm 3000 rpm 3600 rpm
0.0066 0.0088 18 25 20
0.0047 0.0063 13 18 14
POWER / RPM INPUT POWER CAPACITY
kW hp kW hp kW
2800 rpm 3000 rpm 3600 rpm
0.0066 0.0088 18 25 20
0.0047 0.0063 13 18 14
POWER / RPM INPUT POWER CAPACITY
kW hp kW hp kW
2800 rpm 3000 rpm 3600 rpm
0.0109 0.0146 30 41 33
0.0095 0.0128 27 36 29
0.0068 0.0091 19 26 20
POWER / RPM INPUT POWER CAPACITY
kW hp kW hp kW
2800 rpm 3000 rpm 3600 rpm
0.0131 0.0176 37 49 39
0.0111 0.0149 31 42 33
POWER / RPM INPUT POWER CAPACITY
kW hp kW hp kW
3000 rpm 3600 rpm 3800 rpm
0.0152 0.0204 46 61 55
MAX WEIGHT
hp kW hp RPM kg
27 20 27 5000 8.5
19 17 23 5000
MAX WEIGHT
hp kW hp RPM kg
27 20 27 5000 10.3 23
19 17 23 5000
MAX WEIGHT
hp kW hp RPM kg
44 38 51 5000 10.3 23
38 34 46 5000
27 25 33 5000
MAX WEIGHT
hp kW hp RPM kg
53 47 63 5000 13
45 40 54 5000
MAX WEIGHT
hp kW hp RPM kg
73 55 74 5000 13
BELL HSGS.
lb AND NOTES
19 SAE 6, B/W
Max input power 20 kW
BELL HSGS.
lb AND NOTES
SAE 4, 5, 6, B/W
Max input power 20 kW
BELL HSGS.
lb AND NOTES
SAE 4, 5, 6, B/W
Max input power 38 kW.
Ratio 1.482 «B» Pos.
max torque 95 Nm. Ratio
1.792 «B» Pos. max
torque 95 Nm.
BELL HSGS.
lb AND NOTES
29 Yanmar JH
SAE 4, 5, 6, B/W,
Max input power 55 kW
BELL HSGS.
lb AND NOTES
29 SAE 4, 5, 6, B/W, Yanmar JH
Max input power 55 kW.
Ratio 1.556 «B» Pos.
max torque 120 Nm.
Ratio 1.875 «B» Pos.
max torque 120 Nm.
