12 status LEDs indicate:
Group
WiFi 1
WiFi 2/Cellular
GNSS
ETHERNET
ADMIN
LEDs definition
LED
Color
STA
Green
ACT
Blue
STA
Green
ACT
Blue
Green
LINK
Green
Yellow
SPEED
/Green
Red/
DIAG
Green
PWR
Green
Off:
The radio is disabled
Blinking:
The product is not associated
solid "On":
The product is associated
Flashing:
WLAN Tx/Rx activity.
Off:
The radio is disabled
Blinking:
The product is not associated
solid "On":
The product is associated
Flashing:
WLAN Tx/Rx activity.
Off:
The radio is disabled
Blinking:
Position search
Solid "On":
Position established
On:
Link on LAN established
Flashing:
Tx/Rx activity
Yellow:
Connected in 1000 BASE T
Off:
Connected in 100 BASE Tx
or 10 BASE T
Indication of the unit operational state:
OFF:
Power supply is off
Red:
Initialization during 40s after
powering up, then goes Green
Red for more than 2 minutes:
Hardware failure.
Green:
Ready to use
Blinking:
Firmware in flash is not valid;
please load new firmware with
WaveManager
On:
Power supply is applied.
-6-
