PRODUCT SETUP

SETUP
SELECT YOUR METHOD
There are three methods available for setting up the DAP-1365 - using WI-FI Protected
Setup (WPS) (recommended), the QRS Mobile App, or a web browser.
SETTING UP THE DAP-1365 USING WI-FI PROTECTED SETUP (WPS)
NOTE: To connect to a wireless router or AP and extend the Wi-Fi network in your
home, please make sure the source router or AP features a WPS Button.
2
Plug the DAP-1365 into a wall outlet and wait until the
Status/WPS LED is blinking amber. Push the WPS
button on the source wireless router or AP, and then
push the WPS button on the side of the DAP-1365. The
Status/WPS LED will start to flash green.
Please allow up to two minutes for the process to finish.
The Status/WPS LED will turn solid green when the
DAP-1365 has connected successfully to the source
wireless router or AP.
If the Signal Indicator LED has a single amber bar after
the connection process has finished, the DAP-1365 has
established a poor quality connection. To improve the
connection quality, the DAP-1365 should be relocated to
a wall outlet closer to the source wireless router or AP.
The more lit bars on the Signal Indicator LED, the better
the wireless signal.
The DAP-1365 is now ready to share the extended
Wi-Fi network with your PCs and mobile devices.
Connect to the extension network created by the
DAP-1365 using the following network name (SSID):
• 2.4 GHz: (Your router's SSID)-EXT
After WPS, the password of "(Your router's SSID)-EXT"
will be the same as the wireless network it is extending.
